Specification
Internally regulated Type , 2A Pully , 3 Pin Oval Plug
Volts：12
Amps：120
Adjustment Hole (mm)：M8x1.0
Pivot Hole (mm)：10.2
Adjustment to Pivot (mm)：165
Pivot Length (mm)：58
Inside Feet To Feet (mm)：N/A
Pulley (mm)：72
No Of Grooves / Pulley Type：2A
Plug：RP11
OEM Part Number
27060-66040 , 2706066040
101211-7000 ,1012117000
101211-7321 , 1012117321
LRA02273 , LRA2273
Note
There Are Two Different Alternators For These Vehicles With Different Adjustment To Pivot Measurements. This Alternator Is 165mm And The Other Type Is 160mm ( The Measurements Are Close, So Please Take Care When Measuring To Avoid Fitting Issues.) The Other Type Is Lower Output 80AMP And This Is Not Interchangable. Please Check The Original Alternator Before Order.
Fitment
Fit For Toyota Landcruiser FZJ70R 1FZ-E 4.5L 6 cyl Petrol 1992-1998
Fit For Toyota Landcruiser FZJ75 1FZ-E 4.5L 6 cyl Petrol 1985-1999
Fit For Toyota Landcruiser FZJ78R 1FZ-E 4.5L 6 cyl Petrol 1999-2001
Fit For Toyota Landcruiser FZJ79R 1FZ-E 4.5L 6 cyl Petrol 1999-2007
Fit For Toyota Landcruiser FZJ80R 1FZ-E 4.5L 6cyl Petrol 1992-1998
Fit For Toyota Landcruiser FZJ105R 1FZ-E 4.5L 6 cyl Petrol 1998-2002
Package
1 x Alternator
| SKU | ALTER-TA014 |
| Brand | Aftermarket AUTOPARTS |
| Shipping Weight | 6.8000kg |
| Shipping Width | 0.210m |
| Shipping Height | 0.210m |
| Shipping Length | 0.230m |
| Shipping Cubic | 0.010143000m3 |
