Parts for repair only
Item Number:
SMOTOR-CV001M
Features:
12V, 1.4kW, 10TH , CW.
Multi Position Mounting
Suit:
Small & Big Block Fit For CHEV V8
All Gen 1 Family Motors
283 - 307 - 327 - 350 - 383 - 400 Small Block
396 - 427 - 454 - 502 - 572 Big Block
1.4kW Hi-Output 12V
Dual bolt pattern fits either 153 or 168 tooth flywheel / flexplates.
Allows starter to be used with automatic manual transmissions.
Will not fit a staggered mount.
Specifications:
Volts 12V
Kilowatts 1.4kW
Teeth 10TH
Rotation CW
Mount Hole Diameter 2 x 10mm
Flange Diameter 82mm
Pinion At Rest 10mm
Pinion Diameter 28mm
Overall Length 198mm
Mounting Hole Centres 83mm
Package:
1* Starter Motor
This starter comes with 10 teeth, the other type is 9 teeth, please check yours before purchasing.
| SKU | SMOTOR-CV001M |
| Brand | Aftermarket AUTOPARTS |
| Shipping Weight | 5.0000kg |
| Shipping Width | 0.160m |
| Shipping Height | 0.160m |
| Shipping Length | 0.270m |
| Shipping Cubic | 0.006912000m3 |
| Unit Of Measure | ea |
We post items Australia wide via third party delivery contractors. The majority of items have a flat postage fee of $30 which is combined if you purchase more than one item (conditions apply).
Additional postage fees may be charged for bulky items or deliveries to rural or remote locations.
