Parts For Repair Only
Item Number:
SMOTOR-SU001M
Features:
12V, 1.4KW, 9TH, CW
Suit:
Fit For Holden Cruze eng. M15A 1.5L 2002-2003;
Fit For Suzuki Baleno eng. G16B 1.6L 1995-2001;
Fit For Suzuki Baleno eng. 18A 1.8L 1995-2001;
Fit For Suzuki Carry Van eng. G13B 1.3L 1999-2005;
Fit For Suzuki Jimny SN413 eng. M13A, G13B 1.3L 1998-2003;
Fit For Suzuki Ignis eng. M13A 1.3L 2000-2003;
Fit For Suzuki Ignis eng. M15A 1.5L 2000-2003;
Fit For Suzuki Liana eng. M16A 1.6L 2001-2003;
Fit For Suzuki Sierra eng. G13A 1.3L 1985-1998;
Fit For Suzuki Sierra eng. G13B 1.3L 1985-1998;
Fit For Suzuki Swift eng. G16A 1.6L 1988-1998;
Fit For Suzuki Swift eng. G16B 1.6L 1988-1998;
Fit For Suzuki Swift eng. M15A 1.5L 2005-2006;
Fit For Suzuki Vitara eng. G13B 1.3L 1987-1988;
Fit For Suzuki Vitara eng. G16A 1.6L 1988-1998;
Fit For Suzuki Vitara eng. G16B 1.6L 1991-2003;
Please note this starter does not have threaded mounting holes.
NOTE: Does NOT suit Jimny models with Part Number 3110081A3 / M000T84981, check your original type or send your part number to us before placing the order.
Specifications:
Volts 12V
KiloWatts 1.4KW
Teeth 9TH
Rotation CW
Overall Length 230mm
Mounting Hole 9.2mm
Mt Holes Centre 105.5mm
Flange Diameter 66mm
Nose Cone Length 41mm
Pinon Diameter 28mm
Out of Mesh Clearance 4mm
Field Housing Diameter 76mm
Package:
1 * Starter Motor
| SKU | SMOTOR-SU001M |
| Brand | Aftermarket AUTOPARTS |
| Shipping Weight | 5.0000kg |
| Shipping Width | 0.140m |
| Shipping Height | 0.150m |
| Shipping Length | 0.210m |
| Shipping Cubic | 0.004410000m3 |
| Unit Of Measure | ea |
