Specification
Volts：12
Kilowatts (kw)：2.0
Overall Length (mm)：220
Mounting Hole (mm) ：13/M12x1.25
Mount Hole Centres (mm) ：127
Flange Diameter (mm)：82
Nose Cone Length (mm) ：NA
Pinion At Rest (mm)：18
Field Housing Diameter (mm)：70
Teeth：10TH
Rotation：CW
Pinion Diameter (mm)：37
Fitment
Fit For Toyota Fortuner GUN156R 2.8L 4cyl Diesel - 1GD-FTV 08/2015 - ON
Fit For Toyota Granvia GDH303R 2.8L 4cyl Diesel - 1GD-FTV 07/2019 - ON
Fit For Toyota Hiace GDH300R 2.8L 4cyl Diesel - 1GD-FTV 01/2019 - ON
Fit For Toyota Hiace GDH320R 2.8L 4cyl Diesel - 1GD-FTV 01/2019 - ON
Fit For Toyota Hilux GUN122R 2.4L 4cyl Diesel - 2GD-FTV 01/2015 - 12/2019
Fit For Toyota Hilux GUN123R 2.8L 4cyl Diesel - 1GD-FTV 01/2015 - 12/2017
Fit For Toyota Hilux GUN125R 2.4L 4cyl Diesel - 2GD-FTV 01/2015 - ON
Fit For Toyota Hilux GUN126R 2.8L 4cyl Diesel - 1GD-FTV 01/2015 - ON
Fit For Toyota Hilux GUN136R 2.8L 4cyl Diesel - 1GD-FTV 01/2015 - ON
Fit For Toyota Landcruiser Prado GDJ150R 2.8L 4cyl Diesel - 1GD-FTV 06/2015 - ON
Package
1 x Starter Motor
| SKU | SMOTOR-TA025 |
| Brand | Aftermarket AUTOPARTS |
| Shipping Weight | 3.7000kg |
| Shipping Width | 0.150m |
| Shipping Height | 0.120m |
| Shipping Length | 0.285m |
| Shipping Cubic | 0.005130000m3 |
