Specification
Kilowatts (kw)：1.4
Overall Length (mm)：180
Mounting Hole (mm)：M10x1.25
Mount Hole Centres (mm)：105
Flange Diameter (mm)：74
Nose Cone Length (mm)：32
Pinion At Rest (mm)：19
Field Housing Diameter (mm)：80
Teeth：9TH
Rotation：CW
Pinion Diameter (mm)：29
Fitment
Fit For Toyota 4 Runner eng.3RZ 2.7L 2000-ON
Fit For Toyota Hi-Ace RZH100G, 101G, 102V eng.1RZ 2.0L 1989-ON
Fit For Toyota Hi-Ace RZH103, 113, 125 eng.2RZ 2.4L 1989-2000
Fit For Toyota Hi-Ace eng.3RZ 2.7L 2000-2004
Fit For Toyota Hi-Ace eng.5RZ 2.7L 2004-ON
Fit For Toyota Hilux LN609, 109, 309 eng.1RZ, 2RZ 2.7L 1997-2000
Fit For Toyota Hilux RZN149R, 154R eng.3RZ 2.7L 2000-2006
Fit For Toyota Hilux RZN169R, 147R 4WD eng.3RZ-FE 2.7L 1997-1998
Fit For Toyota Landcruiser/Prado 90 Series RZJ95R eng.3RZ-FE 2.7L 41999-02
Fit For Toyota Landcruiser/Prado 120 Series RZJ120R eng.3RZ-FE 2.7L 2003-ON
Package
1 x Starter Motor
| SKU | SMOTOR-TA016 |
| Brand | Aftermarket AUTOPARTS |
| Shipping Weight | 3.4000kg |
| Shipping Width | 0.150m |
| Shipping Height | 0.125m |
| Shipping Length | 0.285m |
| Shipping Cubic | 0.005344000m3 |
